Silverline Radiometers

The SILVERLINE UV RADIOMETERs are rugged, probe-style UV measurement devices. These simple-to-operate radiometers measure UV Intensity (mW/cm²).

The Silver Line radiometers have 2 resolution settings. The x1 setting displays UV intensities from 0 to 19.99 mW/cm², while the x10 setting displays from 0 to 199.90 mW/cm². The rugged metal-housed sensor is capable of withstanding high temperatures and moderate shock. While exposed to the heat of UV curing lamps, the Silver Line radiometer probe can withstand 110°C for up to 10 seconds. The temperature of the housing should not exceed 45°C.

An Auto Off function shuts down the unit after one minute of inactivity to save battery energy.
Th Silver Line uses user replace-able AAA batteries.

The Silver Line series offers 4 models, each measuring a different UV wavelength:
UV-A: 315 – 400nm
UV-B: 280 – 315nm
UV-C: 230 – 280nm
Full UV: 230 – 410nm

UVA Model

M007-150
1225,00 EXW
  • Delivery time : 3-4 weeks

UVB Model

M007-151
955,00 EXW
  • Delivery time : 3-4 weeks

SPECIFICATIONS:

  • Max. Power Input: Sensor input to 1,000 W/cm²
  • Display: LCD, 4 digits
  • Range x1:   0 – 19.99 mW/cm²
  • Range x10:   0 – 199.90 mW/cm²
  • Base Accuracy: ±5%
  • Power Source: AAA batteries (user replace-able)
  • Dimensions (housing): H x W x D 140 x 70 x 13mm
  • Dimensions (sensor): D 40 x 10mm – 1m length
  • Weight: 200 g

Please Specify resolution settings at order !

UVC Model

M007-152
1050,00 EXW
  • Delivery time : 3-4 weeks

All-UV Model

M007-153
1150,00 EXW
  • Delivery time : 3-4 weeks

UVA Sensor

M007-205
505,00 EXW
  • Delivery time : 3-4 weeks
